Fluke T110 Voltage and Continuity Tester

Product Code: FLUT110

Price

£56.95 ex. VAT £68.34 inc. VAT

In Stock

Add To Favourites
Detailed Description

Key Features:

CAT IV 600 V, Cat III 690 V safety rating
Complies with both regulation HSE GS 38 (tip caps) and IEC EN 61243-3: 2010.
4 ways to detect ac/dc voltage
Backlit graduated scale and backlit indicators
Vibration provides tactile feedback (T110, T130, T150).
Audio on/off for testing in quiet areas.
Low battery indicator
Detects voltage even with discharged batteries
Improved probe docking for secure storage
Phase rotation indicator for 3-phase systems
RCD functionality
Two-button controls allow you to draw more current from the circuit under test and intentionally trip Residual-Current Devices (RCDs) remotely
Built in electric torch (T110, T130, T150)
Single-phase voltage offers fast identification of live conductors
Push-on probe tips, probe tip protector and storage accessory
Probe tip protector and storage accessory
Tip protector serves as an extra hand when opening UK electrical safety outlets.
WearGuard™ insulation shows damage to test leads

*Important Calibration Information
This instrument comes complete with a manufacturers calibration certificate. Please be aware that these certificates are generic and may also be time lapsed.
If you would prefer a personalised full traceable calibration certificate applied to the equipment before dispatch, then please select this option from the drop-down menu above, an additional calibration charge will apply.

Experienced professionals trust their job, their reputation and even their personal safety to Fluke electrical test tools. Our family of Two-Pole Voltage Testers are built with state-of-the-art measurement and safety technology, these testers offer everything you expect from Fluke, and a little bit more.
The Fluke two-pole testers are now more rugged and easier to use than ever before.

Overview:

Fast test results the way you need them, with large, easy-to-use buttons, bright backlights, and clear audible and physical indicators designed for any work situation.
Rugged, high-quality construction is built to last. This includes a heavy duty molded case, a thicker cord with wear indicator, sturdy battery case, and well-fitting and durable probe protector.
Enhanced ergonomic design feels good in your hand, is easy to use (even with gloves on) and quick, secure probe docking.
A complete family of testers with the features, functions, and price/performance to fit your applications and preferences

Spares and Accessories:

GS38 Probe Cap
4mm Probe Extensions
Sorft Carrying Case
Holster

Fluke T90/T110/T130/T150 Voltage and Continuity Testers
Specifications	T90	T110	T130	T150
Voltage AC/DC	12V - 690V	12V - 690V	6V - 690V	6V - 690V
Continuity	0 - 400 kΩ
Frequency	0 / 40 - 400 Hz
Phase rotation	-	100 V - 690 V
Resistance measurement	-	-	-	Up to 1999 Ω
Response Time (LED indicator)	< 0.5 s
200 kΩ input impedance	Current draw 3,5 mA @ 690 V Current draw 1,15 mA @ 230 V
7k Ω input impedance (with load buttons pressed)	-	Current draw 30 mA @ 230 V
Safety rating	CAT II 690V CAT III 600V	CAT III 690V CAT IV 600V
IP rating	IP54	IP64	IP64	IP64
Power requirement	2-AA batteries
Net weight	180 g (T90) 280 g (T110. T130, T150)
Size (length, width, height)	23 x 6.5 x 3.8 cm (T90) 26 x 7 x 3.8 cm (T110, T130, T150)
Warranty	2 years
Country of origin	Romania
